Specification
Product Details
- Brand: Inno3D
- Model: N520-3DDV-E3BX
- Dimensions: 1.00" h x
4.00" w x
5.00" l,
.80 pounds
Features
- DVI-I, VGA and HDMI, donot require 6pin power connector, 2GB DDR3 memory onboard
- Support Dual monitors mode: DVI+HDMI or DVI+VGA
- Latest 2012 release
- 128 bit memory bus
- 1 year manufacturer warranty, free 1800 support,Aarding wiwnning premier nvidia partner manufacturer for many years
Product Description
Specification from the Manufacturer:
Nvidia Chipset GT630 D3
Product Cataegory
Series Inno3D
GPU Engine Specs:
CUDA Cores 96
Graphics Clock-Base Clock / Boost Clock (MHz) 810
Processor Clock (MHz) 1620
Texture Fill Rate (billion/sec) 13
Memory Specs:
Memory Clock (MHz) 1333
Standard Memory Config (MB) 2048
Memory Interface SDDR3
Memory Interface Width 128-bit
Memory Bandwidth (GB/sec) 21.3
Feature Support:
OpenGL 4.1
Bus Support PCI-E2.0 X16
Certified for Windows 7 Yes
Supported Technologies (3D Vision, 3D Vision Surround, CUDA, DirectX 11, PhysX, SLI) CUDA, DX11, PhysX
SLI Options Not Supported
Display Support:
Multi Monitor Yes
Maximum Digital Resolution (per output) 2560x1600
Maximum VGA Resolution (per output) 2048x1536
HDCP Yes
HDMI Yes
Standard Display Connectors HDMI, Dual Link DVI, VGA
Internal Audio Input for HDMI Internal
HDMI Version 1.4a
Standard Graphics Card Dimensions:
Length 140mm
Height 98mm
Width Single slot
Thermal and Power Specs:
Maximum GPU Temperature (in C with ambient temperature 55c) 98 C
Maximum Graphics Card Power (W) 65W
Minimum System Power Requirement (W) 300W
Supplementary Power Connectors Not Applicable
Cooler:
Fan Type Axial
Number of Fan 1
Number of Heatpipe Not Acquired
Accessories: included CD Driver
Remark:This card is standard height form factor, it does not fit slim tower
Customer Reviews
Most helpful customer reviews
2 of 2 people found the following review helpful.
By Dan Heinz
I installed the video card once I received it so that i could install my new HD monitor. The card was easy to install and works great so far.
4 of 5 people found the following review helpful.
By Die Defiant
Qualifications: 14 certs in the IT industry. Ex Geek squad manager. almost 2 decades in computer repair and assembly.I have never had an inno3d product before... and I am impressed. This card is a huge bang for the buck. It runs skyrim maxed out on my crappiest system (a tripple core AMD) flawlessly. if you plan on connecting via HDMI I recommend this card. If you have 15-20 bucks more the next model up is even better, but if you're wanting to run modern warfare type games this is more than enough. the people having problems simply dont know what they are doing. this is an easy install and one of the best if not the best in the current price range.
1 of 1 people found the following review helpful.
By M. J. Carter
I was working on an integrated graphics chip for a few months, handled most of what I was doing fine, games I play were ok but there just seemed something a bit "off" about the display. Finally decided the graphics chips were simply not up to what I expected but as I had no real performance issues there was no point in buying a top of the range card. This card I have purchased nicely smooths out all my graphics issues and was at an ideal price point for me.Not for hard core gaming but if you are expecting it to this at such a price then you need to adjust your expectations.
